| Place of Origin: | Shandong |
| Brand Name: | ExceedChem |
| Certification: | ISO9001:2008 |
| Minimum Order Quantity: | 1000kgs |
|---|---|
| Price: | FOB Qingdao USD3.1-3.5/kg |
| Packaging Details: | 20kg/drum or 200kg/drum |
| Delivery Time: | within two weeks after confirming the order |
| Payment Terms: | TT or LC at sight |
| Supply Ability: | 100mt per month |
Quasi-MDI Polyester Polyurethane Prepolymer System
1. Introduction: This polyurethane prepolymer consists of three components A/B/C. Component A is Quasi-MDI polyester prepolymer which ended up with isocynate, Component B is polyester polyol, Component C is 1,4BDO.
2. Characteristic: The final product enjoys good anti resistance ability, good rebound. And the hardness can be adjusted by the different ratios. The color can be adjusted by pigment.
3. Application: This material is used to produce polyurethane sieves, pu rollers and other elastomers.
4. Storage: Keep the material in cool and dry place. Please use it up once drum is open. Or fill nitrogen and seal the drums for keeping the rest material. The shelf life in original package is 12 months.
5. Package: 20kg or 200kg per drum.
6. Properties
|
A |
Type |
Quasi-MDI Polyester Prepolymer |
||||||
|
Appearance |
Transparent liquid |
|||||||
|
Viscosity (55℃)mPa·s |
680 |
|||||||
|
B |
Type |
Polyester Polyol |
||||||
|
Appearance |
Transparent liquid |
|||||||
|
Viscosity (60℃)mPa·s |
800 |
|||||||
|
C |
Type |
1,4 BDO |
||||||
|
Appearance |
Transparent liquid |
|||||||
|
Viscosity (50℃)mPa·s |
30 |
|||||||
|
A/B/C(ratio, by weight) |
100/35/11.8 |
100/50/11.2 |
100/65/10.6 |
100/80/10 |
100/90/9.3 |
100/110/8.6 |
||
|
Catalyst/ weight of A+B+C % |
0.1%-0.2% |
|||||||
|
Operation temperature/ ℃ |
A/B/C=55℃/60℃/50℃ |
|||||||
|
Gel time/min |
2-6, can be adjusted by catalyst |
|||||||
|
Post cure time(100℃)/h |
At least 10 hours |
|||||||
|
Product Appearance |
White solid |
White solid |
White solid |
White solid |
White solid |
Transparent liquid |
||
|
Hardness/Shore A |
94±2 |
90±2 |
85±2 |
80±2 |
75±2 |
70±2 |
||
|
Tensile strength/MPa |
53 |
52 |
51 |
48 |
45 |
40 |
||
|
Elongation at break /% |
570 |
600 |
610 |
620 |
630 |
640 |
||
|
100% modulus/Mpa |
8.9 |
6.1 |
4.5 |
3.8 |
3.0 |
2.3 |
||
|
300% modulus/Mpa |
16.2 |
11.2 |
8.8 |
6.9 |
6.0 |
4.9 |
||
|
Tear strength (with nick)/ (KN/m) |
125 |
112 |
98 |
82 |
73 |
65 |
||
|
Tear strength (without nick)/ (KN/m) |
47 |
38 |
32 |
26 |
23 |
21 |
||
|
Rebound 30℃/% |
46 |
49 |
53 |
54 |
56 |
58 |
||
|
DIN abrasion /mm3 |
43 |
38 |
36 |
35 |
32 |
29 |
||
|
Specific gravity (g/cm3) |
1.21-1.23 |
|||||||
*Gel time can be adjusted by catalyst.
