| Place of Origin: | Shandong, China |
| Brand Name: | Exceedchem |
| Certification: | ISO9001, SGS |
| Model Number: | EX101 |
| Minimum Order Quantity: | 1000kg |
|---|---|
| Price: | USD1.00/kg-USD4.00/kg |
| Packaging Details: | 200kg net steel drum |
| Delivery Time: | within two weeks after confirming the order |
| Payment Terms: | T/T, L/C at sight |
| Supply Ability: | 100mt per month |
Polyurethane System for Air Filter EX101
1. Introduction
A component of Polyurethane system of air filter (EX101-A)is composed of hyperactive poly polyols, cross linking agent, compound catalyst and so on. B component (EX101-B)is modified isocyanate, and it is micro-pore elastomer which adopts cold molding. It has excellent mechanical and anti-fatigue property. Also, with short production cycle, high efficiency and low energy consumption. So it is widely used for manufacturing cars, ships, construction machinery, generator set and other internal combustion machinery's air filter cores etc.
2. Typical properties
|
|
EX101-A |
EX101-B |
|
Appearance |
Pale yellow viscous liquid |
Brown liquid |
|
Hydroxyl value mgKOH/g |
70-90 |
&sh; |
|
-NCO% content % |
&sh; |
26-30 |
|
Viscosity(25℃) mPa.S |
1000-2000 |
150-350 |
|
Specific gravity(20℃) g/ml |
1.20±0.02 |
1.20±0.05 |
|
storage temperature ℃ |
≤25 |
≤25 |
|
Storage stability ※ Month |
6 |
>12 |
※ Store in original barrel in a dry place in recommending temperature
Recommended formula EX101-A /EX101-B 100 / 30-50
Reaction characteristics (Material temperature is 20℃) actual value varies depending on processing conditions
|
|
Manual mixing |
High pressure machine |
|
|
Cream time |
S |
15-30 |
8-15 |
|
Gel time |
S |
40-60 |
30-45 |
|
Tack-free time |
S |
90-120 |
60-100 |
|
Mold temperature |
℃ |
40-50 |
40-50 |
|
Demould time |
min |
4-6 |
4-6 |
3. Typical foaming characteristics
|
Hardness |
Shore A |
20-50 |
|
Density |
Kg/m3 |
300-1000 |
|
Tensile strength |
MPa |
≥0.9 |
|
Tear strength |
N/mm |
≥1.0 |
|
Elongation at break |
% |
≥90 |
|
40%compression ratio(70℃,22h) |
% |
≤10 |
The values above are typical which are measured by our company. To our products, the data included in the legal field has no constraints.
